Galvanized sheet size list

Galvanized sheet size list
Galvanized sheet size list
Galvanized sheet size list
Galvanized sheet size list
Galvanized sheet size list
Brand
HDT steel
length
6-12m
standard
GB/ASTM/JIS/DIN
Delivery time
7-15 days
payment method
T/T L/C
Product customization
Yes
Galvanized sheet refers to the surface of a layer of zinc plated steel sheet, its size list covers the thickness and width of different specifications of steel sheet.The recommended standard thickness, length and width of galvanized sheet and its allowable deviation are listed in relevant product standards. Generally speaking, the thicker the galvanized sheet allows the greater error, rather than the fixed 0.02-0.04mm, thickness deviation is also based on the yield degree, tensile coefficient and other different requirements, length and width deviation is generally in 5mm, the thickness of the sheet is generally between 0.4-3.2mm.

1.What is the size of galvanized sheet?


Galvanized sheet size specification(unit:mm)
0.4*10000.4*1250
0.5*10000.5*1250
0.6*10000.6*1250
0.7*10000.75*1250
0.8*10000.8*1250
0.9*10000.9*1250
1.2*10001.0*1250
1.4*15001.08*1250
1.5*10001.1*1250
1.5*10001.2*1250
1.8*15001.8*1250
2.0*10001.95*1250
2.0*10002.0*1250

2.Wich is better galvanized sheet or stainless steel sheet?


Galvanized sheet and stainless steel sheet
materialsgalvanized sheetstainless steel sheet
conception

the surface of the steel plate is coated with metallic zinc

steel resistant to air, steam, water and other weakly corrosive media

hardnesslittlelarge

chemical amount

Cr,Ni,Ti,Mn,N,Nb,Mo,Si,CuC,P,Si,Mn,S

welding degree

littlelarge
adhibitionconstruction, light industry, automobile, agriculture, animal husbandry, fishery and commercemedical and hygiene requirements are higher in the catering industry
pricecheap and practicalmore expensive

3.Does galvanized sheet metal rust?


    Galvanized iron sheet surface metal zinc oxidation will rust, although galvanized sheet has a certain corrosion resistance, rust resistance, but the ability of galvanized sheet is also limited, the degree and time of rust and galvanized sheet in the environment has a great relationship. If the galvanized sheet is placed in the case of high acid and high pollution for a long time, the metal zinc on the surface will be oxidized and rust slightly, but this situation will appear in 20 years later.But if the galvanized sheet is put in the room, and keep dry, do not let the galvanized sheet with water stains and corrosion liquid, then the probability of galvanized sheet rust will become smaller. Galvanized sheet corrosion and rust is a very normal phenomenon, because galvanized sheet contains other impurities, such as, carbon, manganese, silicon, and other metals, it is easy to produce corrosion effect, resulting in galvanized sheet rust. Galvanized steel plate is also divided into cold galvanized plate and hot galvanized plate, usually cold galvanized plate than hot galvanized steel plate to use a shorter number of years.
